CAD & DRAFTING SUPPORT / OHIO, USA
Your next project.
Clearly defined.
From an old drawing to your next assembly. Practical CAD support for manufacturers who need to keep moving.
Explore our capabilities One project or ongoing support.
BUILT AROUND YOUR WORKFLOWSOLIDWORKS2D + 3D CADDRAWING PACKAGESMANUAL QUOTING
01 / CAPABILITIES
The extra capacity
behind your next deadline.
Focused drafting and modeling support.
Only the work you need, when you need it.
Clear scope. Clear deliverables.
CAD and documentation services—not a manufacturing marketplace. Final requirements and design approval stay with your team.
02 / THE PROCESS
Less back-and-forth.
More forward motion.
You bring the starting point.
We put the scope in writing.
Review your quote
We personally review your project and clarify deliverables, price, and schedule.
Put the work in motion
Approve the scope before work begins. Receive the agreed files and included revisions.
03 / PROJECT EXAMPLES
From starting point
to working documentation.
Illustrative workflow imagery.
Approved Haldan work will be added as it becomes available.
EXAMPLE / 01ILLUSTRATIVE IMAGEA legacy part, rebuilt
Paper drawing → editable 3D model
Model + neutral CAD export
EXAMPLE / 02ILLUSTRATIVE IMAGEAn assembly, organized
Existing parts → assembly documentation
Assembly + BOM + drawingsEXAMPLE / 03ILLUSTRATIVE IMAGEA drawing set, brought current
Marked-up PDFs → revised drawing package
Updated drawings + revision recordSUPPORT THAT GROWS WITH YOUR WORKLOAD
A CAD partner.
Not another full-time hire.
For recurring drawing updates, new parts, and the backlog that never quite clears. Arrange monthly capacity around your actual needs.
Agreed monthly scope and capacity
One point of contact
Consistent files and drawing standards
Pricing based on your workload
No one-size-fits-all subscription.
We’ll define the arrangement together.
THE PERSON BEHIND THE DRAWINGS
Small by design.
Hands-on by experience.
Haldan is led by Christopher Hayes, with hands-on experience supporting CAD and documentation in pump manufacturing.
You work directly with the person doing the modeling and drafting—from the first question to the final file.
Christopher Hayes FOUNDER / HALDANBEFORE YOU START
A few useful answers.
Do I need an account to request a quote?
No. Submit as a guest with your email address. A free account adds quote tracking, project history, and company workspace access.
What if I only have a sketch or an old drawing?
That is a valid starting point. Include dimensions, reference photos, and what you need. We will identify missing information before agreeing on scope.
How are pricing and turnaround determined?
Every project is reviewed manually. Your quote will specify deliverables, price, schedule, and included revisions. No automated pricing.
What files can I send?
PDF, STEP, IGES, STL, DWG, DXF, SolidWorks, images, and ZIP packages. Clear handwritten drawings are welcome too. Uploads are limited to 10 files, 50 MB each, and 200 MB total.
Who owns the finished work?
Ownership and native file delivery will be specified in your written quote and agreed terms. Tell us which formats you need before work begins.
Can we arrange an NDA?
Yes. Select the NDA option in the quote form before sending confidential files. Haldan will contact you to put the higher confidentiality standard in writing.
GET IN TOUCH
Want to explain it first?
Send a quick description and any questions. You’ll hear back within one business day.
